JB INSTALL PANASONIC DH-3US1MS 3.6kW 9 SAFETY FEATURES AG+ CRYSTAL MATERIAL 3-WAY SHOWER HEAD WATER HEATER -NON-PUMP

Enjoy a safe and refreshing shower experience with the Panasonic DH-3US1MS Water Heater.

U Series Water Heater DH-3US1MS

U Series Water Heater
 DH-3US1MS Blissful Showers
  for Comfort & Wellbeing

U Series Water Heater
  DH-3US1MS   Features Your Everyday Shower Clean & Worry-free

Protects against bacteria

Relax & Refresh with Comfortable Shower

Gentle & Comfortable Water Texture

3-way Shower Head Normal

Wide

Spot

Modernly Sleek

Get Inspired

Specs

Size and Weight

Height

385mm

Width

210mm

Depth

78mm

Weight

1.5kg

*Please check the minimum space requirements for installation.

Rated Power : 3.6 kW
  Power Supply : 240 V , 50 Hz

Protects against fire & electrical hazards with 9 safety features

Protects against bacteria with Ag+ Crystal Material

Gentle & comfortable water texture with 3-way shower head

 Basic Specification

• PUMP/ NO PUMP

1. Non Pump

• TYPE

1. Non LCD type (Analogue)

• Power Supply

1. 240 V, 50 Hz

• Rated Power

1. 3.6 kW

• Water Pressure

1. Minimum
• 0.10 kgf/cm²
2. Maximum
• 3.87 kgf/cm²

• Dimensions (h x w x d) mm

1. 385 x 210 x 78

• Main Unit Weight (kg)

1. 1.5 kg

• Body Colour

1. Skin Silver

Standard Regulation

• SURUHANJAYA TENAGA (Safety)

ELB indication method

• Red ELB light

Water Stop System

• One Push On/Off Switch

9 Safety Features

• 1. Water Splash Prood Case Cover

1. IEC 60529 (IP2X)

• 2. Durable Copper Heater Unit

1. Yes

• 3. On Push On/Off Switch

1. Yes

• 4. Insulated Structure

1. Yes. IEC 60529 (IP2X)

• 5. Built-in Earth Leakage Breaker (ELB)

1. Yes

• 6. Water Flow Sensor

1. Yes

• 7. Non-flammable Material Cover

1. Yes

• 8. Manual Reset Thermostat

1. Yes

• 9. Auto Thermal Cut-off

1. 55ºC

Comfort Features

• U-memory

1. -

• U-mode

1. -

• On/Off Pump function

1. -

• Ag+ Antibacterial material

1. Yes

• 3-way Shower

1. Normal, Wide, Spot
